Software-Hardware Decoupling
Built-in standard DeviceNet V2.0 slave stack; host only needs universal Modbus — zero protocol development.
Designed for industrial equipment makers. We turn complex DeviceNet protocols into production-ready hardware solutions, ensuring rapid market deployment for your products.
Built-in standard DeviceNet V2.0 slave stack; host only needs universal Modbus — zero protocol development.
Integrated CAN electrical isolation with surge & EMI protection for harsh automation sites.
Hardware DIP switch sets station number 0–63 — no host software configuration required.
Multi-layer error correction eliminates packet loss & corruption with millisecond-level response.
125K / 250K / 500Kbps full-range auto-match to both legacy and new DeviceNet masters.
No MCU binding; fully compatible with STM32F1 / F4 / H7 and mainstream controllers.
| System Solution | One-Stop DeviceNet Field Module + Universal Host Interface | A complete DeviceNet field-control building block from one vendor — standard V2.0 slave stack in hardware-firmware with zero secondary development, so your product ships faster. |
|---|---|---|
| System Real-Time Performance | Millisecond-level response · zero packet loss | Deterministic millisecond-level command response keeps your production line moving — commands answered in time, every time, even under heavy bus traffic. |
| System Reliability | 2.5 kV CAN isolation · multi-layer ECC | Industrial-grade electrical isolation and error correction keep every node stable in harsh EMI and surge environments — fewer failures, lower maintenance. |
| System Scalability | Stations 0 – 63 · hardware DIP addressing | 64 addressable stations with simple DIP-switch addressing drop into legacy and new DeviceNet networks alike — scale up without re-engineering. |
| Integrated Engineering | Universal Modbus (TTL / RS485) · no MCU binding | Any MCU engineer gets started fast with universal Modbus — compatible with STM32F1 / F4 / H7 and mainstream controllers, with no vendor lock-in. |
| System Power Flexibility | 24V DC ±10% · industrial standard | Directly compatible with control cabinets and automation gear — reverse-polarity protected and tolerant of real-world shop-floor power. |
| Bus Protocol Standard | DeviceNet V2.0 Slave · CAN 2.0B | An open, internationally standardized fieldbus — producer/consumer model with 8-byte payloads, interoperable with any certified DeviceNet master. |
| Bus Speed Flexibility | Auto-adaptive 125 / 250 / 500 kbps | Covers the full DeviceNet baud range with automatic adaptation — works out of the box with legacy and new masters. |
| Whole-System Environment | –40°C to +85°C | Extended industrial temperature range — dependable in unheated shops, sealed cabinets and outdoor enclosures without special cooling. |
| Rapid Deployment | DIP station · 5-pin open-style connector | Set the station number on the hardware DIP switch and wire with the standard DeviceNet open-style connector — no software configuration needed. |
| Electrical Protection | Reverse-polarity · over-current | Built-in reverse-polarity and over-current protection safeguard the node and the network — lower replacement cost and less downtime. |
Four production scenarios where the platform replaces a hand-built DeviceNet stack.
Cyclic exchange for drives and motor starters along a single trunk line, with trunk and drop diagnostics.
Remote I/O blocks and valve islands polled on the same bus as the control logic.
Flow, pressure and temperature nodes for glass, pipe and chemical lines.
Legacy DeviceNet nodes kept in service while the controller platform is upgraded.
